Clinical study on simultaneous integrated boost intensity-modulated radiotherapy with different segmentation modes in the treatment of 92 cases of brain metastases from lung cancer

doi:10.3877/cma.j.issn.1674-6902.2026.01.012

Abstract

Abstract:

Objective

To explore the effects of synchronous intensity-modulated radiotherapy (SIB-IMRT) with different segmentation modes on intracranial progression, cognitive function, immune function, and quality of life in patients with lung cancer brain metastases (BM).

Methods

A prospective study was conducted on 92 patients with brain metastases (BM) admitted to Cangzhou Central Hospital from November 2021 to December 2024. They were randomly divided into Group A 49 cases (40Gy/20Fx whole brain+ local addition of 60Gy/20Fx) and Group B 43 cases (37.5Gy/15Fx whole brain+ local addition of 52.5Gy/15Fx). The intracranial progression free survival time (iPFS) was recorded. The flow cytometry was performed to detect blood lymphocyte subsets before and after radiotherapy. Kaplan-Meier curves was used to analyze the impact of different segmentation modes on iPFS. The effects of different segmentation modes on cognitive function, quality of life, and cellular immune function (CD3⁺, CD4⁺, CD8⁺ %) were analyzed by repeated measures method of variance.

Results

During a median follow-up of 9.93 months, there were 21 deaths and 71 survivors. In addition, 59 patients (64.13%) experienced intracranial progression/recurrence, while the duration of iPFS 4.90 months (95%CI: 3.42-6.38 months) in Group A was less than the duration of iPFS 12.60 months (95%CI: 10.28~14.92 months) in Group B, Log-Rank=12.621, P=0.000. 44 treatment-related adverse events occurred, and there was no statistically significant difference in the incidence of adverse events between the two groups (P>0.05). At 4 and 6 months after radiotherapy, the Montreal cognitive scores of Group B (23.13±1.45) and (23.09±2.00) were higher than that of Group A (20.97±2.35) and (18.35±2.41), P=0.000; the Barthel index of daily living activities in group B (8.74±2.47) was higher than that in group A (6.95±0.39) at 6 months after radiotherapy (P=0.001). After radiotherapy for 2 months, CD8⁺ % 32.50(23.90, 41.10) in group B was higher than that in group A 27.10(17.65, 36.03)(P=0.001). Repeated analysis of variance showed that CD8⁺ % (Fgroup×time=6.966, P=0.012) had inter group interactions.

Conclusions

The whole brain 37.5Gy/15Fx+ local dose 52.5Gy/15Fx regimen can prolong iPFS in patients with multiple BM of lung cancer and help to maintain their immune function, cognitive ability, and quality of life after radiotherapy.

Key words: Bronchogenic carcinoma, Bronchogenic carcinoma with brain metastases, Simultaneous integrated boost intensity-modulated radiotherapy, Segmentation dose, Intracranial progression, Cognitive function, Quality of life, Immune function

Chiluan Ma, Dianjun Jia, Dongdong Wei, Liang Shi, Xiaowei Zhang, Yue Zhao. Clinical study on simultaneous integrated boost intensity-modulated radiotherapy with different segmentation modes in the treatment of 92 cases of brain metastases from lung cancer[J]. Chinese Journal of Lung Diseases(Electronic Edition), 2026, 19(01): 76-82.

/ / Recommend

Add to citation manager EndNote|Ris|BibTeX

URL: https://zhfbjbzz.cma-cmc.com.cn/EN/10.3877/cma.j.issn.1674-6902.2026.01.012

https://zhfbjbzz.cma-cmc.com.cn/EN/Y2026/V19/I01/76

Figures/Tables 5

References 29

1	Ghaderi S, Mohammadi S, Mohammadi M, et al. A systematic review of brain metastases from lung cancer using magnetic resonance neuroimaging: Clinical and technical aspects[J]. J Med Radiat Sci, 2024, 71(2): 269-289.
2	Vogelbaum MA, Brown PD, Messersmith H, et al. Treatment for brain Metastases: ASCO-SNO-ASTRO Guideline[J]. J Clin Oncol, 2022, 40(5): 492-516.
3	中国医疗保健国际交流促进会肿瘤内科学分会，中国医师协会肿瘤医师分会. Ⅳ期原发性肺癌中国治疗指南(2024版)[J]. 中华肿瘤杂志，2024, 46(7): 595-636.
4	Liu J, Xu J, Ye W, et al. Whole-brain radiotherapy combined with anlotinib for multiple brain metastases from non-small cell lung cancer without targetable driver mutation: A single-arm, phase Ⅱ study[J]. Clin Med Insights Oncol, 2022, 16: 11795549221079185.
5	中国医师协会肿瘤医师分会，中国医疗保健国际交流促进会肿瘤内科分会. 肺癌脑转移中国治疗指南(2021年版)[J]. 中华肿瘤杂志，2021, 43(3): 269-281.
6	Uto M, Ogura K, Katagiri T, et al. Interfractional target changes in brain metastases during 13-fraction stereotactic radiotherapy[J]. Radiat Oncol, 2021, 6(1): 140.
7	徐珊，方志祥，刘丽丽，等. Monaco计划系统Inc参数对全脑同步局部加量容积旋转调强放射治疗计划的影响[J]. 中国医学装备，2023, 20(7): 15-21.
8	石宏伟，皮国良. 《肺癌脑转移中国治疗指南(2021年版)》更新解读[J]. 临床内科杂志，2021, 38(10): 710-712.
9	中国抗癌协会神经肿瘤专业委员会. 中国肿瘤整合诊疗指南——脑转移瘤[J]. 癌症，2023, 42(6): 304-318.
10	Wadden J, Ravi K, John V, et al. Cell-free tumor DNA (cf-tDNA) liquid biopsy: current methods and use in brain tumor immunotherapy[J]. Front Immunol, 2022, 13: 882452.
11	符炳彪，赵泽宇，安思龙，等. 基于cfDNA脑脊液液体活检在髓母细胞瘤的研究进展[J]. 海南医学院学报，2023, 29(18): 1430-1434.
12	Jia X, Wang Z, Huang F, et al. A comparison of the mini-mental state examination (MMSE) with the montreal cognitive assessment (MoCA) for mild cognitive impairment screening in Chinese middle-aged and older population: a cross-sectional study[J]. BMC Psychiatry, 2021, 21(1): 485.
13	朱池豪，王天伟，杨溪，等. 预测肺癌脑转移瘤预后的列线图研究[J]. 临床神经外科杂志，2023, 20(6): 658-663.
14	谢东，周杰，蔡志标，等. 脑转移瘤立体定向放射外科联合多学科治疗研究进展[J]. 中华神经外科疾病研究杂志，2025, 19(3): 169-173.
15	Chia BSH, Leong JY, Ong ALK, et al. Randomised prospective phase Ⅱ trial in multiple brain metastases comparing outcomes between hippocampal avoidance whole brain radiotherapy with or without simultaneous integrated boost: HA-SIB-WBRT study protocol[J]. BMC Cancer, 2020, 20(1): 1045.
16	Palmer JD, Klamer BG, Ballman KV, et al. Association of long-term outcomes with stereotactic radiosurgery vs whole-brain radiotherapy for resected brain Metastasis: A secondary analysis of the N107C/CEC.3 (Alliance for Clinical Trials in Oncology/Canadian Cancer Trials Group) randomized clinical trial[J]. JAMA Oncol, 2022, 8(12): 1809-1815.
17	Yang S, Ma Y, Xu Y, et al. Dosimetric and clinical analysis of pseudo-progression versus recurrence after hypo-fractionated radiotherapy for brain metastases[J]. Radiat Oncol, 2023, 18(1): 30.
18	Chen C, Guo Y, Chen Y, et al. The efficacy of laser interstitial thermal therapy for brain metastases with in-field recurrence following SRS: systemic review and meta-analysis[J]. Int J Hyperthermia, 2021, 38(1): 273-281.
19	Rava P, Sioshansi S, DiPetrillo T, et al. Local recurrence and survival following stereotactic radiosurgery for brain metastases from small cell lung cancer[J]. Pract Radiat Oncol, 2015, 5(1): e37-e44.
20	Gulsever CI, Sencer A, Dolen BurakD, et al. Hippocampal radiation exposure and cognitive outcomes after single-fraction gamma knife radiosurgery for benign sellar and parasellar lesions: A prospective study[J]. Stereotact Funct Neurosurg, 2025: 1-17.
21	Zeng H, Zhong M, Chen Z, et al. A dosimetric comparison of non-coplanar volumetric modulated arc therapy and non-coplanar fixed field intensity modulated radiation therapy in hippocampus-avoidance whole-brain radiation therapy with a simultaneous integrated boost for brain metastases[J]. Front Oncol, 2025, 23(14): 1428329.
22	Pokhrel D, Sood S, Lominska C, et al. Potential for reduced radiation- induced toxicity using intensity-modulated arc therapy for whole-brain radiotherapy with hippocampal sparing[J]. J Appl Clin Med Phys, 2015, 16(5): 131-141.
23	Singh NP, Khurana R, Sapru S, et al. Long term outcome and late toxicity Of SIB-IMRT in definitive management of head and neck cancers in patients not suitable for chemo-radiotherapy[J]. J Cancer Res Ther, 2022, 18(6): 1461-1468.
24	Oktavianda YD, Permata TBM. Role of memantine to mitigate radiation- induced cognitive dysfunction in brain metastasis patient receiving whole brain radiotherapy: a systematic review[J]. Radiat Oncol J, 2024, 42(4): 281-294.
25	Wu N, Wang Z, Guo X, et al. Dose-effect relationship of linear accelerator based stereotactic radiotherapy for brain metastases[J]. Radiat Oncol, 2023, 18(1): 177.
26	Mesny E, Jacob J, Noël G, et al. Specific radiosensitivity of brain structures (areas or regions) and cognitive impairment after focal or whole brain radiotherapy: A review[J]. Cancer Radiother, 2025, 29(3): 104625.
27	Wang Q, Li S, Qiao S, et al. Changes in T lymphocyte subsets in different tumors before and after radiotherapy: a meta-analysis[J]. Front Immunol, 2021, 12: 648652.
28	Köksal H, Herbst M, Perreira P, et al. Pre-existing intratumoral stem-like CD8＋ T cells drive radiotherapy-induced tumor immunity[J]. Cell Rep, 2025, 44(4): 115566.
29	刘宝刚，李磊强，孙立哲，等. 生物免疫疗法联合放化疗对NSCLC患者CD3^＋、CD4^＋/CD8^＋、NK的影响[J/OL]. 中华肺部疾病杂志(电子版), 2023, 16(5): 661-663.

临床资料	A组(n＝49)	B组(n＝43)	t/Z/χ²值	P值
实验室指标[M₅₀(P₂₅，P₇₅)]
癌胚抗原(ng/ml)	8.59(3.11，34.80)	11.81(2.86，41.58)	0.250	0.803
神经元特异性烯醇化酶(ng/ml)	15.83(12.00，21.07)	14.58(11.32，23.00)	0.472	0.637
细胞角蛋白21-1(ng/ml)	5.65(3.45，17.25)	5.05(3.28，14.45)	0.441	0.659
病理亚型[n(%)]			1.266	0.261
肺腺癌	43(87.76)	34(79.07)
肺鳞癌及其它	6(12.24)	9(20.93)
T分期[n(%)]			0.393	0.531
1~2	26(53.06)	20(46.51)
3~4	23(46.94)	23(53.49)
N分期[n(%)]			0.210	0.647
0~2	33(67.35)	27(62.79)
3	16(32.65)	16(37.21)
表皮生长因子受体突变[n(%)]	23(46.94)	25(58.14)	1.151	0.283
脑部放疗参数[M₅₀(P₂₅，P₇₅)]
肿瘤转移数量(个)	1.00(1.00，4.00)	2.00(1.00，5.00)	1.137	0.256
确诊至脑放疗间隔(d)	6.00(2.75，56.25)	7.00(1.75，23.50)	0.520	0.603
总肿瘤靶区(cc)	2.12(1.22，2.58)	1.81(0.82，4.29)	0.875	0.381
治疗史[n(%)]
肺部手术	19(38.78)	11(25.58)	1.814	0.178
肺部放疗	15(30.61)	13(30.23)	0.002	0.969
转移灶手术	3(6.12)	1(2.33)		0.620
化疗	35(71.43)	27(62.79)	0.778	0.378
酪氨酸激酶抑制剂	9(18.37)	5(11.63)	0.806	0.369

临床资料	A组(n＝49)	B组(n＝43)	t/Z/χ²值	P值
实验室指标[M₅₀(P₂₅，P₇₅)]
癌胚抗原(ng/ml)	8.59(3.11，34.80)	11.81(2.86，41.58)	0.250	0.803
神经元特异性烯醇化酶(ng/ml)	15.83(12.00，21.07)	14.58(11.32，23.00)	0.472	0.637
细胞角蛋白21-1(ng/ml)	5.65(3.45，17.25)	5.05(3.28，14.45)	0.441	0.659
病理亚型[n(%)]			1.266	0.261
肺腺癌	43(87.76)	34(79.07)
肺鳞癌及其它	6(12.24)	9(20.93)
T分期[n(%)]			0.393	0.531
1~2	26(53.06)	20(46.51)
3~4	23(46.94)	23(53.49)
N分期[n(%)]			0.210	0.647
0~2	33(67.35)	27(62.79)
3	16(32.65)	16(37.21)
表皮生长因子受体突变[n(%)]	23(46.94)	25(58.14)	1.151	0.283
脑部放疗参数[M₅₀(P₂₅，P₇₅)]
肿瘤转移数量(个)	1.00(1.00，4.00)	2.00(1.00，5.00)	1.137	0.256
确诊至脑放疗间隔(d)	6.00(2.75，56.25)	7.00(1.75，23.50)	0.520	0.603
总肿瘤靶区(cc)	2.12(1.22，2.58)	1.81(0.82，4.29)	0.875	0.381
治疗史[n(%)]
肺部手术	19(38.78)	11(25.58)	1.814	0.178
肺部放疗	15(30.61)	13(30.23)	0.002	0.969
转移灶手术	3(6.12)	1(2.33)		0.620
化疗	35(71.43)	27(62.79)	0.778	0.378
酪氨酸激酶抑制剂	9(18.37)	5(11.63)	0.806	0.369

淋巴细胞	A组(n＝49)		B组(n＝43)		Z值	P值
淋巴细胞	例数[n(%)]	[M₅₀(P₂₅，P₇₅)]	例数[n(%)]	[M₅₀(P₂₅，P₇₅)]	Z值	P值
CD3^＋%
基线	49(100.00)	71.97(58.78，80.03)	43(100.00)	67.18(53.12，77.70)	1.390	0.165
放疗2个月	43(87.76)	56.65(47.88，63.95)	42(97.67)	52.90(44.80，61.10)	1.538	0.124
变化值	43(87.76)	10.35(20.31，2.91)	42(97.67)	12.88(28.18，3.30)	0.743	0.458
CD4^＋%
基线	49(100.00)	60.20(49.58，67.88)	43(100.00)	60.80(46.05，65.35)	0.566	0.571
放疗2个月	43(87.76)	36.40(23.90，45.23)	42(97.67)	42.00(24.60，50.00)	1.292	0.196
变化值	43(87.76)	26.20(37.88，15.40)	42(97.67)	19.80(29.30，6.00)	1.951	0.051
CD8^＋%
基线	49(100.00)	34.00(28.28，42.82)	43(100.00)	33.55(25.70，55.23)	0.375	0.708
放疗2个月	43(87.76)	27.10(17.65，36.03)	42(97.67)	32.50(23.90，41.10)	3.248	0.001
变化值	43(87.76)	5.80(17.18，0.38)	42(97.67)	1.30(9.20，1.60)	2.000	0.046
CD4^＋/CD8^＋
基线	49(100.00)	1.58(1.32，2.20)	43(100.00)	1.61(1.13，2.26)	0.441	0.659
放疗2个月	43(87.76)	1.11(0.68，1.75)	42(97.67)	0.99(0.56，1.28)	1.406	0.160
变化值	43(87.76)	0.64(1.14，0.13)	42(97.67)	0.59(1.35，0.11)	0.650	0.515

淋巴细胞	A组(n＝49)		B组(n＝43)		Z值	P值
淋巴细胞	例数[n(%)]	[M₅₀(P₂₅，P₇₅)]	例数[n(%)]	[M₅₀(P₂₅，P₇₅)]	Z值	P值
CD3^＋%
基线	49(100.00)	71.97(58.78，80.03)	43(100.00)	67.18(53.12，77.70)	1.390	0.165
放疗2个月	43(87.76)	56.65(47.88，63.95)	42(97.67)	52.90(44.80，61.10)	1.538	0.124
变化值	43(87.76)	10.35(20.31，2.91)	42(97.67)	12.88(28.18，3.30)	0.743	0.458
CD4^＋%
基线	49(100.00)	60.20(49.58，67.88)	43(100.00)	60.80(46.05，65.35)	0.566	0.571
放疗2个月	43(87.76)	36.40(23.90，45.23)	42(97.67)	42.00(24.60，50.00)	1.292	0.196
变化值	43(87.76)	26.20(37.88，15.40)	42(97.67)	19.80(29.30，6.00)	1.951	0.051
CD8^＋%
基线	49(100.00)	34.00(28.28，42.82)	43(100.00)	33.55(25.70，55.23)	0.375	0.708
放疗2个月	43(87.76)	27.10(17.65，36.03)	42(97.67)	32.50(23.90，41.10)	3.248	0.001
变化值	43(87.76)	5.80(17.18，0.38)	42(97.67)	1.30(9.20，1.60)	2.000	0.046
CD4^＋/CD8^＋
基线	49(100.00)	1.58(1.32，2.20)	43(100.00)	1.61(1.13，2.26)	0.441	0.659
放疗2个月	43(87.76)	1.11(0.68，1.75)	42(97.67)	0.99(0.56，1.28)	1.406	0.160
变化值	43(87.76)	0.64(1.14，0.13)	42(97.67)	0.59(1.35，0.11)	0.650	0.515

不良事件	A组(n＝49)	B组(n＝43)	χ²值	P值
内耳和迷路功能障碍(1~2级)	3(6.12)	1(2.33)		0.620
眼部功能障碍(1~2级)	0(0.00)	1(2.33)		0.467
消化道毒性反应(1~2级)	5(10.20)	2(4.65)	1.005	0.316
疲劳	12(24.49)	4(9.30)	3.677	0.055
1~2级	11(22.45)	4(9.30)	2.901	0.089
3级	1(2.17)	0(0.00)		0.476
头痛	10(20.41)	3(6.98)	3.405	0.065
1~2级	9(18.37)	3(6.98)	2.620	0.106
3级	1(2.04)	0(0.00)		0.476
放射性皮炎(1~2级)	1(2.04)	1(2.33)
代谢和营养紊乱(1~2级)	1(2.04)	1(2.33)
认知功能障碍	13(26.53)	7(16.28)	1.415	0.234
1~2级	11(22.45)	7(16.28)	0.554	0.457
3级	2(4.08)	0(0.00)		0.497
皮肤和皮下组织毒性反应(1~2级)	12(24.49)	6(13.95)	1.616	0.204
