Feasibility and influencing factors analysis of electromagnetic navigation bronchoscopy guided methylene blue preoperative localization of pulmonary nodules

doi:10.3877/cma.j.issn.1674-6902.2026.02.004

Abstract

Abstract:

Objective

To analyze the effectiveness and safety of electromagnetic navigation bronchoscopy (ENB)-guided methylene blue localization in thoracoscopic surgery for pulmonary nodules, compare it with computed tomography (CT)-guided percutaneous localization, and explore its clinical feasibility and influencing factors.

Methods

A retrospective study was conducted on 248 patients who underwent pulmonary nodule localization and video-assisted thoracoscopic surgery at our hospital from October 2022 to October 2024. Propensity score matching at a 1︰1 ratio resulted in 124 cases in the ENB localization group and 124 cases in the CT localization group. Localization time, localization success rate, and complications were recorded. LASSO regression and logistic regression were used to analyze factors affecting ENB localization time.

Results

The proportion of solid nodules (12.10% vs. 4.03%, P=0.048) and the proportion of bronchus sign (15.32% vs. 7.26%, P=0.045) were higher in the ENB localization group than in the CT localization group. Localization time (15.00 min vs. 16.15 min, P=0.086) and thoracoscopic surgery time (81.50 min vs. 90.00 min, P=0.068) were lower in the ENB localization group compared to the CT localization group (P>0.05). Successful localization of pulmonary nodules was achieved in 122 cases (98.39%) in the ENB localization group, which was higher than the 121 cases (97.58%) in the CT localization group (P=0.651). The rates of hemopneumothorax (0.00% vs. 4.84%, P=0.013) and overall complications (4.84% vs. 17.74%, P=0.001) were lower in the ENB localization group than in the CT localization group. In the ENB localization group, there were 6 cases (4.84%) of complications, with no cases of hemopneumothorax or hemoptysis. Multivariate logistic regression analysis showed that pulmonary nodule location (OR=4.084, P=0.005), pulmonary nodule diameter (OR=2.452, P=0.032), and operator experience (OR=3.227, P=0.005) were risk factors affecting ENB localization time.

Conclusion

ENB-guided methylene blue localization has a success rate comparable to CT-guided localization, with a lower risk of complications. Clinical optimization of ENB localization outcomes should consider pulmonary nodule location, pulmonary nodule diameter, and operator experience.

Key words: Pulmonary nodules, Electromagnetic navigation bronchoscopy, Computed tomography, Localization time

Kai Wang, Qingquan Ren, Qiang Cao, Qiang Liu, Shuai Yang, Jia Wang. Feasibility and influencing factors analysis of electromagnetic navigation bronchoscopy guided methylene blue preoperative localization of pulmonary nodules[J]. Chinese Journal of Lung Diseases(Electronic Edition), 2026, 19(02): 205-211.

/ / Recommend

Add to citation manager EndNote|Ris|BibTeX

URL: https://zhfbjbzz.cma-cmc.com.cn/EN/10.3877/cma.j.issn.1674-6902.2026.02.004

https://zhfbjbzz.cma-cmc.com.cn/EN/Y2026/V19/I02/205

Figures/Tables 7

References 32

1	Henschke C, Huber R, Jiang L, et al. Perspective on management of low-dose computed tomography findings on low-dose computed tomography examinations for lung cancer screening. from the international association for the study of lung cancer early detection and screening committee[J]. J Thorac Oncol, 2024, 19(4): 565-580.
2	钱春蕊，周燕，张晶，等. 高分辨率CT与多层螺旋CT在肺结节及早期肺癌中的应用[J/OL]. 中华肺部疾病杂志(电子版), 2024, 17(5): 827-830.
3	Han Y, Zhang W, Xu P, et al. One-stage versus two-stage video-assisted thoracic surgery for synchronous bilateral pulmonary nodules: protocol for a single center, non-randomized clinical trial (OTVATS-1)[J]. BMC Surgery, 2025, 25(1): 45-50.
4	Zhang Q, Wu X, Yang H, et al. Advances in the treatment of pulmonary nodules[J]. Respiration, 2024, 103(3): 134-145.
5	Pan C, Deng W, Zhao Y, et al. Precise localization techniques for small pulmonary nodules: what is next？[J]. J Thorac Dis, 2025, 17(9): 7366.
6	Cardillo G, Petersen RH, Ricciardi S, et al. European guidelines for the surgical management of pure ground-glass opacities and part-solid nodules: Task force of the european association of cardio-thoracic surgery and the european society of thoracic surgeons[J]. Eur J Cardio-Thorac Surg, 2023, 64(4): ezad222.
7	Wang Y, Chen E. Advances in the localization of pulmonary nodules：a comprehensive review[J]. J Cardiothorac Surg, 2024, 19(1): 396.
8	Wang L, Sun D, Gao M, et al. Computed tomography-guided localization of pulmonary nodules prior to thoracoscopic surgery[J]. Thoracic Cancer, 2023, 14(2): 119-126.
9	王亮亮，李远庆，刘建，等. 肺结节术前CT定位在胸腔镜中的应用价值[J]. 医学影像学杂志，2023, 33(6): 979-982.
10	Yin C, Chen Y, Zhang R, et al. Analysis of complication risk factors in preoperative computed tomography-guided hookwire location of pulmonary nodules[J]. Eur J Med Res, 2024, 29(1): 369-375.
11	He R, Ming C, Lei Y, et al. Preoperative pulmonary nodule localization：A comparison of hook wire and Lung-pro-guided surgical markers[J]. Clin Respir J, 2024, 18(1): e13726.
12	Feng Q, Zhou J, Dong N, et al. Factors influencing the accuracy and safety of preoperative computed tomography (CT)-guided soft hook-wire localization for pulmonary nodules: a comprehensive analysis[J]. Quantitat Imag Med Surg, 2024, 14(3): 2309.
13	Song JW, Park IK, Bae SY, et al. Electromagnetic navigation bronchoscopy-guided dye marking for localization of pulmonary nodules[J]. Ann Thorac Surg, 2022, 113(5): 1663-1669.
14	陈香，张亚杰，韩丁培，等. 电磁导航支气管镜引导下肺结节术前定位183例的单中心临床分析[J]. 中国胸心血管外科临床杂志，2023, 30(11): 1539-1544.
15	Xu Y, Liu H, Qin Y, et al. Localization strategies for deep lung nodule using electromagnetic navigation bronchoscopy and indocyanine green fluorescence: a technical note[J]. J Thorac Dis, 2024, 16(11): 7910-7919.
16	Zheng X, Cao L, Zhang Y, et al. A novel electromagnetic navigation bronchoscopy system for the diagnosis of peripheral pulmonary nodules: a randomized clinical trial[J]. Ann Am Thorac Soc, 2022, 19(10): 1730-1739.
17	Tsai YM, Kuo YS, Chen YY, et al. Initial learning experience for electromagnetic navigation bronchoscopy: A Surgeon’s experience while introducing the navigation technology in pulmonary lesion diagnosis[J]. J Med Sci, 2024, 44(3): 125-132.
18	Xue M, Lan K, Yan X, et al. Electromagnetic navigation bronchoscopy-guided preoperative lung nodule localization in video-assisted thoracic surgery (VATS): a learning curve analysis[J]. Translat Lung Cancer Res, 2024, 13(10): 2561.
19	Wang J, Huang H, Xue Q, et al. Preoperative localization of pulmonary nodules by electromagnetic navigation bronchoscopy combined with methylene blue injection[J]. J Thorac Dis, 2024, 16(9): 6196-6203.
20	钟宏源，李文涛. 肺结节外科治疗进展[J]. 中国综合临床，2024, 40(1): 41-48.
21	Du J, Fu YF, Lv YN. Preoperative localization for lung nodules: a meta-analysis of bronchoscopic versus computed tomography guidance[J]. Wideochir Inne Tech Maloinwazyjne, 2022, 17(4): 601-610.
22	Yang Q, Han K, Lv S, et al. Virtual navigation bronchoscopy-guided intraoperative indocyanine green localization in simultaneous surgery for multiple pulmonary nodules[J]. Thorac Cancer, 2022, 13(20): 2879-2889.
23	Wang R, Chen Y, Wang C, et al. A better option for localization of multiple pulmonary nodules in the ipsilateral lung: electromagnetic navigation bronchoscopy-guided preoperative localization[J]. Transl Lung Cancer Res, 2025, 14(3): 775-784.
24	Tan Y, Shen S, Wang C, et al. Comparison of electromagnetic navigation bronchoscopy localization and CT-guided percutaneous localization in resection of lung nodules: A protocol for systematic review and meta-analysis[J]. Medicine (Baltimore), 2024, 103(38): e39760.
25	Xia T, Li Y, Shen Z, et al. Comparison of safety and anxiety/depression in computed tomography-guided hook-wire localization versus electromagnetic navigation bronchoscopy-guided localization: a retrospective cohort study[J]. J Thorac Dis, 2024, 16(1): 401-413.
26	Qu R, Tu D, Hu S, et al. Electromagnetic navigation bronchoscopy-guided microwave ablation combined with uniportal video-assisted thoracoscopic surgery for multiple ground glass opacities[J]. Ann Thorac Surg, 2022, 113(4): 1307-1315.
27	Li Y, Chen W, Xie F, et al. Novel electromagnetic navigation bronchoscopy system for the diagnosis of peripheral pulmonary nodules: a prospective, multicentre study[J]. Thorax, 2023, 78(12): 1197-1205.
28	Zhang H, Zhang C, Li L, et al. Small pulmonary nodule localization techniques in the era of lung cancer screening: A narrative review[J]. Int J Surg, 2025, 111(3): 2624-2632.
29	Kim D, Han JY, Baek JW, et al. Effect of the respiratory motion of pulmonary nodules on CT-guided percutaneous transthoracic needle biopsy[J]. Acta Radiolog, 2023, 64(7): 2245-2252.
30	Zeng Y, Gou X, Yin P, et al. The influence of respiratory movement on preoperative CT-guided localization of lung nodules[J]. Clin Radiol, 2024, 79(7): e963-e970.
31	Yang Y, Qin C, Ma Y, et al. Application of computed tomography-guided hook-wire localization technique in thoracoscopic surgery for small pulmonary nodules (≤10 mm)[J]. J Cardiothorac Surg, 2023, 18(1): 99.
32	Xu Y, Liu H, Qin Y, et al. Localization strategies for deep lung nodule using electromagnetic navigation bronchoscopy and indocyanine green fluorescence: a technical note[J]. J Thorac Dis, 2024, 16(11): 7910.

临床资料	CT定位组(n＝124)	ENB定位组(n＝124)	t/χ²/Z值	P值
吸烟史[n(%)]			0.895	0.639
从不	109(87.90)	111(89.52)
既往	8(6.45)	9(7.26)
现在	7(5.65)	4(3.23)
慢性阻塞性肺疾病[n(%)]	13(10.48)	15(12.10)	0.161	0.688
ASA分级[n(%)]			0.107	0.744
Ⅰ/Ⅱ	100(80.6)	102(82.26)
Ⅲ/Ⅳ	24(19.3)	22(17.74)
平均动脉压[mmHg，(±s)]	101.42±14.69	99.53±12.12	1.105	0.270
肺结节数量[n(%)]			0.107	0.744
1	100(80.5)	102(82.26)
≥2	24(19.35)	22(17.74)
肺结节位置[n(%)]			1.967	0.579
右上叶	58(46.77)	69(55.65)
右下叶	25(20.16)	21(16.94)
左上叶	26(20.97)	22(17.74)
左下叶	15(12.10)	12(9.68)
肺结节直径[mm，M(Q₂₅，Q₇₅)]	10.00(8.00，12.00)	10.00(7.00，14.00)	－0.210	0.834
距胸膜距离[mm，M(Q₂₅，Q₇₅)]	5.00(3.00，14.38)	5.00(2.14，14.95)	－0.756	0.450
肺结节密度[n(%)]			6.059	0.048
纯磨玻璃结节	43(34.68)	34(27.42)
混合型磨玻璃结节	76(61.29)	75(60.48)
实性结节	5(4.03)	15(12.10)
支气管征[n(%)]	9(7.26)	19(15.32)	4.026	0.045
恶性CT征象[n(%)]	62(50.0)	50(40.32)	2.345	0.126

临床资料	CT定位组(n＝124)	ENB定位组(n＝124)	t/χ²/Z值	P值
吸烟史[n(%)]			0.895	0.639
从不	109(87.90)	111(89.52)
既往	8(6.45)	9(7.26)
现在	7(5.65)	4(3.23)
慢性阻塞性肺疾病[n(%)]	13(10.48)	15(12.10)	0.161	0.688
ASA分级[n(%)]			0.107	0.744
Ⅰ/Ⅱ	100(80.6)	102(82.26)
Ⅲ/Ⅳ	24(19.3)	22(17.74)
平均动脉压[mmHg，(±s)]	101.42±14.69	99.53±12.12	1.105	0.270
肺结节数量[n(%)]			0.107	0.744
1	100(80.5)	102(82.26)
≥2	24(19.35)	22(17.74)
肺结节位置[n(%)]			1.967	0.579
右上叶	58(46.77)	69(55.65)
右下叶	25(20.16)	21(16.94)
左上叶	26(20.97)	22(17.74)
左下叶	15(12.10)	12(9.68)
肺结节直径[mm，M(Q₂₅，Q₇₅)]	10.00(8.00，12.00)	10.00(7.00，14.00)	－0.210	0.834
距胸膜距离[mm，M(Q₂₅，Q₇₅)]	5.00(3.00，14.38)	5.00(2.14，14.95)	－0.756	0.450
肺结节密度[n(%)]			6.059	0.048
纯磨玻璃结节	43(34.68)	34(27.42)
混合型磨玻璃结节	76(61.29)	75(60.48)
实性结节	5(4.03)	15(12.10)
支气管征[n(%)]	9(7.26)	19(15.32)	4.026	0.045
恶性CT征象[n(%)]	62(50.0)	50(40.32)	2.345	0.126

手术情况	CT定位组(n＝124)	ENB定位组(n＝124)	χ²/Z值	P值
病理亚型[n(%)]			2.373	0.796
非典型腺瘤样增生	1(0.81)	1(0.81)
原位腺癌	42(33.87)	42(33.87)
微浸润腺癌	45(36.29)	37(29.84)
浸润性腺癌	26(20.97)	29(23.39)
转移性腺癌	1(0.81)	3(2.42)
良性	9(7.26)	12(9.68)
亚甲蓝剂量[ml，M(Q₂₅，Q₇₅)]	0.40(0.30，0.60)	0.40(0.30，0.50)	－1.400	0.162
手术类型[n(%)]			1.203	0.548
Wedge切除	63(50.81)	59(47.58)
肺段切除	61(49.19)	64(51.61)
肺叶切除	0(0.0)	1(0.81)
手术切缘[mm，M(Q₂₅，Q₇₅)]	20.00(12.25，25.00)	20.00(15.00，20.00)	－0.701	0.483
单肺通气时长[mm，M(Q₂₅，Q₇₅)]	56.00(34.25，82.00)	52.50(30.00，72.75)	－1.670	0.095
术者经验[n(%)]			1.362	0.243
≤100例	45(36.29)	54(43.55)
>100例	79(63.37)	70(56.45)
定位时间[mm，M(Q₂₅，Q₇₅)]	16.15(12.88，23.16)	15.00(12.80，18.35)	－1.718	0.086
胸腔镜手术时间[mm，M(Q₂₅，Q₇₅)]	90.00(69.25，120.00)	81.50(61.00，107.00)	－1.822	0.068

手术情况	CT定位组(n＝124)	ENB定位组(n＝124)	χ²/Z值	P值
病理亚型[n(%)]			2.373	0.796
非典型腺瘤样增生	1(0.81)	1(0.81)
原位腺癌	42(33.87)	42(33.87)
微浸润腺癌	45(36.29)	37(29.84)
浸润性腺癌	26(20.97)	29(23.39)
转移性腺癌	1(0.81)	3(2.42)
良性	9(7.26)	12(9.68)
亚甲蓝剂量[ml，M(Q₂₅，Q₇₅)]	0.40(0.30，0.60)	0.40(0.30，0.50)	－1.400	0.162
手术类型[n(%)]			1.203	0.548
Wedge切除	63(50.81)	59(47.58)
肺段切除	61(49.19)	64(51.61)
肺叶切除	0(0.0)	1(0.81)
手术切缘[mm，M(Q₂₅，Q₇₅)]	20.00(12.25，25.00)	20.00(15.00，20.00)	－0.701	0.483
单肺通气时长[mm，M(Q₂₅，Q₇₅)]	56.00(34.25，82.00)	52.50(30.00，72.75)	－1.670	0.095
术者经验[n(%)]			1.362	0.243
≤100例	45(36.29)	54(43.55)
>100例	79(63.37)	70(56.45)
定位时间[mm，M(Q₂₅，Q₇₅)]	16.15(12.88，23.16)	15.00(12.80，18.35)	－1.718	0.086
胸腔镜手术时间[mm，M(Q₂₅，Q₇₅)]	90.00(69.25，120.00)	81.50(61.00，107.00)	－1.822	0.068

肺结节特征	CT定位组(n＝124)				ENB定位组(n＝124)				组间成功率
肺结节特征	定位失败(n＝3)	定位成功(n＝121)	χ²值	P值	定位失败(n＝2)	定位成功(n＝122)	χ²值	P值	χ²值	P值
距胸膜距离			0.374	0.541			0.165	0.684	0.243	0.622
≤10 mm	2(66.67)	81(66.94)			1(50.0)	78(63.93)
>10 mm	1(33.33)	40(33.06)			1(50.0)	44(36.07)
肺结节位置			3.073	0.381			9.970	0.019	1.875	0.599
右上叶	0(0.0)	58(47.93)			0(0.0)	69(56.56)
右下叶	1(33.33)	24(19.83)			2(100.0)	19(15.57)
左上叶	1(33.33)	25(20.66)			0(0.0)	22(18.03)
左下叶	1(33.33)	14(11.57)			0(0.0)	12(9.84)
肺结节直径			0.489	0.485			－	0.217	1.485	0.223
≤10 mm	1(33.33)	65(53.72)			2(100.0)	56(45.90)
>10 mm	2(66.67)	56(46.28)			0(0.0)	66(54.10)
肺结节密度			0.140	0.932			1.328	0.515	5.845	0.054
纯磨玻璃结节	1(33.33)	42(34.71)			0(0.0)	34(27.87)
混合型磨玻璃结节	2(66.67)	74(61.16)			2(100.0)	73(59.84)
实性结节	0(0.0)	5(4.13)			0(0.0)	15(12.30)
